ISUZU N Series Road Vacuum Cleaner Truck 4x2 130hp 6cbm Electronic Control

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Fuel | Diesel | Use | Burnishing |
---|---|---|---|
Cleaning Process | Cold Water Cleaning | Control Type | Electronic Control |
Auxiliary Engine | Diesel Type | Flushing Type | High Pressure Jetting |
Sweeper | 4 Sets | Others | Suction Divice With Automatic Avoidance Function |
Usage | Road Sweeping And Jetting Cleaning | Sweeping Speed | 3-20km/H |
Sweeping Width | Max 3.5 Meters | Tank | Clean Water Tank And Dirty Tank |
Product Name | Road Sweeper Truck, Road Jetting Truck | Specification | 6900mm*220mm0*2670mm |
After-sales Service | Provided | Type | Sweep And Suck Type |
Transmission Type | Manual | Customization | Available | Customized Request |
High Light | N Series Road Vacuum Cleaner Truck,Road Vacuum Cleaner Truck 4x2,Vacuum Road Sweeper Truck 130hp |
Product Description
ISUZU N Series 4x2 130hp 6cbm Road Sweeper Vacuum Truck
Product Description
What is a street sweeper truck?
A sweeper truck is a truck with brushes underneath for sweeping surfaces and gutters. They're often referred to as street sweepers or street cleaners, road sweeper, vacuum sweeper, etc, but they don't just clean streets. These versatile vehicles can be used in a number of ways. Any area that is paved can be cleaned with one of these trucks. They clean all manner of waste off of city streets, typically late at night or early in the morning, and they make street cleaning much more time-efficient than it used to be.
Different types of Street Sweeper
According to different Fuctions of the Sweeper Truck, we mainly can divide them into three types:
1. Vacuum Suction Truck, which has no sweepers but is with a long suction divice in the middle and two vice suction divices at side. This truck normally be used in the places where have heavy dust like ement factory, coal depot, seaports, etc.
2. Street Sweeper Truck, which is with a long suction divices in the middle and two sweepers at both sides. This type Truck can be used in streets where has little dust and garbages on the road could be easily cleaned.
3. Jetting Sweeper Truck, which has three fuctions: High pressure water jetting, Sweeping and Suction. This type truck not only has the sweeping and suction, but also can high pressure jetting garbages sticked on the ground. High Pressure Water Jetting Sweeper Truck makes road the cleanest.
Product Parameters
Vehicle performance and parameters | |||
Item | Parameter | Unit | |
Working Performance | Max sweep width | 3.2 | m |
Sweep speed | 3-20 | km/h | |
Max sweep capacity | 60000 | m2/h | |
Max inhalation of granularity | ≥110 | mm | |
Angle of unloading | ≥45 | . | |
Volume of water tank | 3000 | L | |
Volume of garbage tank | 6000 | L | |
Driving Performance | Max speed | 95 | km/h |
Max gradeability | 30 | % | |
Braking distance | ≤10 | m | |
Min turning diameter | ≤13.6 | m | |
Quality Parameter | Curb weight | 5100 | kg |
GVW | 7300 | kg | |
Dimension Parameter | Overall dimensions | 6830×2220×2450 | mm |
Wheelbase | 3815 | mm | |
Track front | 1680 | mm | |
Track rear | 1640 | mm | |
Front suspension | 1155 | mm | |
Rear suspension | 1860 | mm | |
Approach angle | 17 | . | |
Departure angle | 25 | . | |
Minimum Ground Clearance | 200 | mm |
