Diesel ISUZU Road Sweeper Truck 2000L Water Tank 3000L Sewage Dusty Tank
| Place of Origin | China |
|---|---|
| Brand Name | ISUZU |
| Certification | CGC，ISO9001:2015，TUV SUD，PV，CNAS |
| Model Number | CL5051GSSL1 |
| Minimum Order Quantity | 1 UNIT |
| Price | USD 29200- USD 35200/ UNIT |
| Delivery Time | 45-60 work days |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Fuel | Diesel | Payload | 5t |
|---|---|---|---|
| Use | Burnishing | Cleaning Process | Cold Water Cleaning |
| Brushes | 4sets | Cleaning Width | 2.4 To 4.2m |
| Tire | 10.00r20 | Working Speed | 6km/H |
| Material | Carbon Steel | Volume | 2000L Water Tank |
| Size | 5995X2450X3250mm | HS Code | 8705909990 |
| Warranty | 12 Month | Type | Sweep And Suck Type |
| Transmission Type | Manual | Emission Standard | Euro 4 |
| Customization | Available | Customized Request | ||
| High Light | ISUZU Road Sweeper Truck 3000L,Diesel ISUZU Road Sweeper Truck |
||
Product Description
ISUZU ELF 2000L Water Tank with 3000L Sewage Dusty Tank Road Sweeper Truck
Product Description
This road sweeper truck with function sweeping road and water sprinkling cleaning road.
The structure design with two sweepers in the middle and nozzle at the back ensure wide sweeping width and high efficiency. in addition, it helps to facilitate sweeper installation and nozzle adjustment and maintenance. the nozzle has a short elevation in front and a large ground clearance, ensuring ease of passage for the vehicle.
~If you have any question or optional require, please feel free to chat me at below
The structure design with two sweepers in the middle and nozzle at the back ensure wide sweeping width and high efficiency. in addition, it helps to facilitate sweeper installation and nozzle adjustment and maintenance. the nozzle has a short elevation in front and a large ground clearance, ensuring ease of passage for the vehicle.
Product Parameters
| Vehicle performance and parameters | |||
| Item | Parameter | Unit | |
| Working Performance | Max sweep width | 3.2 | m |
| Sweep speed | 3-20 | km/h | |
| Max sweep capacity | 60000 | m2/h | |
| Max inhalation of granularity | ≥110 | mm | |
| Angle of unloading | ≥45 | . | |
| Volume of water tank | 3000 | L | |
| Volume of garbage tank | 6000 | L | |
| Driving Performance | Max speed | 95 | km/h |
| Max gradeability | 30 | % | |
| Braking distance | ≤10 | m | |
| Min turning diameter | ≤13.6 | m | |
| Quality Parameter | Curb weight | 5100 | kg |
| GVW | 7300 | kg | |
| Dimension Parameter | Overall dimensions | 6830×2220×2450 | mm |
| Wheelbase | 3815 | mm | |
| Track front | 1680 | mm | |
| Track rear | 1640 | mm | |
| Front suspension | 1155 | mm | |
| Rear suspension | 1860 | mm | |
| Approach angle | 17 | . | |
| Departure angle | 25 | . | |
| Minimum Ground Clearance | 200 | mm |
|
FAQ
1.Payment term.
-T/T,30% deposit ,and pay the blance before shippment from our factory
-L/C,L/C price is expensive than T/T price.
-T/T,30% deposit ,and pay the blance before shippment from our factory
-L/C,L/C price is expensive than T/T price.
2.What about quality ?
Our truck are brand new truck,Our survival is based on quality and credit standing is the guarantee of our success. We will do as we can to treat customers honestly, manage flexibly, guarantee high quality but low price, and keep high efficiency.
our company truck pass ISO,3C,ASME certification.
Our truck are brand new truck,Our survival is based on quality and credit standing is the guarantee of our success. We will do as we can to treat customers honestly, manage flexibly, guarantee high quality but low price, and keep high efficiency.
our company truck pass ISO,3C,ASME certification.
3.Visit our factory
Our factory are in suizhou city,hubei province china.
You can take train or plane to arrive wuhan citry(wuhan city is the capital of hubei province) .and our driver will pick up you at wuhan railway station or wuhan tianhe airport.
Our factory are in suizhou city,hubei province china.
You can take train or plane to arrive wuhan citry(wuhan city is the capital of hubei province) .and our driver will pick up you at wuhan railway station or wuhan tianhe airport.
And if need the invitation letter ,pls send your private information and company information to me.
~If you have any question or optional require, please feel free to chat me at below
THANKS FOR REFERENCE
